Camnetics GearTeqAI for Inventor v2011.15.32.331 x64 英文正式版(齒輪設計插件軟體)
安裝序號:
序號產生器放至於keygen夾內
內容說明:
Camnetics GearteqAI 是一個可以方便地設計實體齒輪的Inventor插件。它可以建立光滑的
漸開線齒廓。
英文說明:
Some of GearTeq's enhanced features:
Work on Multiple types of components in the same assembly
See any changes to the geometry instantly on the display
window
Multiple gears created as a single
SolidWorks part
Internal splines can be used as a bore on all components
Modifying CAD parts created by GearTeq is very easy
Automatically create assemblies in
SolidWorks with proper
mating
Ten standard planetary gear systems are available with a
few clicks
High ratio cycloid set (a single eccentrically mounted
planet and a fixed internal gear)
On screen animations to help you visualize the working gears
Warnings when GearTeq detects something in your design that
may not be proper
3D wire frame with some surface shading
Create XY outputs of the involute points in Excel and text
files
Create data sheets using Excel or text files
A description of each parameter is in the lower section of
the property grid
Involute profile modification using linear or parabolic
deviation for spur and helical gears
Automatic balance of addendum modification for spur and
helical gears
Create additional tooth profiles that take into
consideration the shrinkage of molded plastic gear teeth
Deviation chart for DIN splines, hub space width/shaft
tooth thickness fit
An easy to use sizing for standard spur gears
Programmed on a platform that will allow greater
enhancements in the future
圖片說明:
![]()
